The EM-HD-NCP acts as an HDMI monitor by emulating the EDID found in a typical HDMI LCD and by asserting the HPD (Hot Plug Detection) to the HDMI video source. Most PCs and laptops require a special handshake from the display before they output video. This handshake involves reading the EDID table from the monitor.

The EDID contains information such as Native or supported resolutions and Video Formats. Some older equipment may not support the EDID properly and the end result is that you often can't get video from your PC to external display.

If you connect the HDMI output of your laptop to a “dumb” HDMI Switch, you laptop will notice when you switch away from that input since it will notice a disconnect. This interrupts and affects the video on your laptop, especially of you have extended your desktop. You can use the EM-HD-NCP to “fool” your laptop into sensing that it is connected to a monitor regardless of which input is selected on the HDMI switcher.

EMCEE200 is a multiview presentation switcher scaler with Picture-in-Picture (PIP) and Picture-Over-Picture (POP) capabilities.

It can process up to four 4K@60 video sources with zero latency and gives “CONFIDENCE” and “PRESENT” HDMI outputs in different window layouts.

With a built-in dual MIC mixer and a wide range of Audio Embedding and De-Embedding options, EMCEE is a perfect companion for any type of presentation.

EMCEE can not only record the presentation to an external storage device but also provides USB3.0 4K capture to stream live with no additional hardware.

HIVE Node is an IoT based controller that seamlessly connects to the HIVE Cloud. It can control and monitor any device that has IP, RS232, contact closure, and IR interface. HIVE Nodes are the job handlers for HIVE Cloud.

They seamlessly connect any third-party AV device to the cloud. Multiple HIVE Nodes can be used in an installation to handle the workload, which allows you to infinitely scale. With built-in PoE and wireless connectivity, HIVE Node effortlessly integrates into a wide range of automation, data collection, and control applications.

HIVE Touch is an intuitive capacitive touch panel interface that seamlessly connects with HIVE Cloud. It renders HIVE's control panels natively, to give a dynamic user experience. It provides access and asset management to the devices that are connected to the HIVE Cloud. HIVE Touch also emulates a software Node and acts as a control system for the entire room and controls all IP devices in the room without the need for additional hardware. With built-in PoE and wireless connectivity, HIVE Touch can be integrated into a wide range of applications.

The HIVE driverless control system leverages the best in modern IoT, legacy control, and automation systems to deliver a superior end-to-end AV solution. With major improvements to the industry's three major pillars in AV control; software, interface, and hardware, we've created an infinity scalable and affordable AV solution that is easy to manage.

Unlike what is in the market today, our HIVE Nodes do not require the need to maintain a centralized server, the purchase of gateway devices, or the installation of on-premise “brain” units. Instead, our HIVE Nodes are designed to directly connect to all existing legacy or wirelessly connect to IP enabled hardware devices.

Install and change your control system without the need to hire a highly-skilled programmer. Use a simple to use drag and drop interface to customize your AV control setup or use one of our professionally designed setup templates for even quicker installation. Control 3rd party devices and automation tools by utilizing HIVE Control's extensive list of device drivers and community fed REST API repository for effortless integration.

Our subscription-based asset management platform allows our customers to service remotely, analyze, and scale without the cost of licenses or per room costs. Connect an unlimited number of rooms under one subscription.

The AMP-7040 is a compact, economical and energy-efficient (Class D) stereo to mono audio amplifier at 70 V or 100 V with 3 inputs (2 line in and 1 balanced microphone). The Versatile design is compatible with dynamic, condenser or wireless microphones with fully adjustable control options including RS-232, IR, and front panel buttons. Functions include EQ control and microphone mixer.

The AMP-7040 is a perfect for classrooms, meeting rooms, boardrooms, sports bars and more.

The AMP-4840 is a compact, economical and energy efficient (Class D) mono / stereo audio amplifier with 3 inputs (2 line in and 1 balanced mic). Versatile design is compatible with dynamic, condenser or wireless microphones with fully adjustable control options including RS-232, IR, and front panel buttons. Functions include bridge connection, dual-mono, EQ control, and microphone mixer.

The Hall Research HD-AUD-IO is an award winning HDMI audio extractor (de-embedder) and inserter (embedder). The product also provides many benefits such as:

EDID management with learn and upload EDID functions

HDMI cable equalization (supports cable lengths to 20 meters)

Re-clocks video and negotiates HDCP overcoming incompatibility issues

RS-232 and contact closure to mute HDMI audio (or video)

Generates HDMI signal with audio only with no HDMI input

Simultaneously extracts Audio and allowing embedding of external audio

The product provides one HDMI input with a corresponding HDMI output. The HDMI input audio signal simultaneously extracts to both 2-channel L/R analog and Digital SPDIF (TOSLINK).

The product provides two audio inputs (analog and digital). Users can select which audio to embed in the HDMI output. It can be the same as the original HDMI audio (pass-thru), SPDIF digital, or 3.5mm L/R analog.

Advanced EDID management allows users to control the video portion as well as the audio part of the EDID. The EDID presented to the video source connected to the HDMI input can pass from the downstream device or emulate an EDID from internal memory. The device can also “Learn” the EDID connected to its HDMI output.

The product has a video bandwidth of 18 Gbps and supports resolutions up to 4K@60 Hz 4:4:4 with HDR. It supports HDCP 2.2 as well as HDCP 1.4 if needed.

This HDBaseT extension kit is comprised of a compact Sender (UH-BTX-S) and corresponding Receiver (UH-BTX-R).

The UH-BT and UH-BTX are a family of HDBaseT™ compliant Senders and Receivers used to extend uncompressed HDMI video and RS-232 control signals up to 230 ft (-BT models) or 328 ft (-BTX models) over a single CAT5e/CAT6 UTP cable.

The extenders are comprised of a Sender (-S) and a Receiver (-R) and extend all PC and HD resolutions without compression, up to 4K UHD.

Full-duplex RS-232 extension is provided via 3-pin terminal blocks, supporting all baud rates up to 115,200 bps.

This HDBaseT extension kit is comprised of a compact Sender (UH-BT-S) and corresponding Receiver (UH-BT-R).

The UH-BT and UH-BTX are a family of HDBaseT™ compliant Senders and Receivers used to extend uncompressed HDMI video and RS-232 control signals up to 230 ft (-BT models) or 328 ft (-BTX models) over a single CAT5e/CAT6 UTP cable.

The extenders are comprised of a Sender (-S) and a Receiver (-R) and extend all PC and HD resolutions without compression, up to 4K UHD.

Full-duplex RS-232 extension is provided via 3-pin terminal blocks, supporting all baud rates up to 115,200 bps.

This product is a Class A HDBaseT compliant Receiver that supports 100meter Cat6 range and is used to extend HDMI, RS-232, IR, and Ethernet (100BaseT) up to 100 meters (328 feet) using a single Cat6 cable.

Since the product uses the HDBaseT standard, video is extended pixel-by-pixel with no compression or latency. The extender supports all PC and HDTV Resolutions including 4K @ 30 Hz 4:4:4 or 4K @ 60 Hz 4:2:0. The IR extension preserves the modulation (carrier) frequency thereby providing compatibility to most standards.

Receiver includes a universal 5v power supply. IR emitter and IR detector cables are included.

As a member of Genesis Digital Matrix™ series of switchers, the HSM-44-BX matrix provides exceptional quality, intuitive operation and powerful control methods that are hallmarks of Hall Technologies' video matrix switches.

The 4K matrix is a 4×4 cross-point switch in a compact 1-RU enclosure. Each output has integrated video splitter so that simultaneous HDMI and HDBaseT are provided.

The HDBaseT outputs extend HDMI, IR, RS-232, Ethernet, and Power over a single CAT6 cable to 100m (328 ft). The HDBaseT outputs are compatible with all compliant HDBaseT receivers such as the Hall Techonologies' HBX-R which is a cost-effective Receiver that provides HDMI, IR, RS-232 and IP (Ethernet) extension and gets its power from the matrix for maximum convenience.

The HSM-44-BX supports HDMI resolutions up to 4K @ 30 Hz 4:4:4 and 4K @ 60 Hz 4:2:0. It also supports HDCP 2.2 and 1.4, 3D, deep-color. PCM, Dolby, DTS, and HD audio standards. The matrix intelligently calculates EDID for each input based on the EDID of the connected sinks.
